ZTYQJ SERIES MOBILE TRAILER TYPE VACUUM FILTER OIL MACHINE
Product use:
The company according to the needs of the market, and constantly developed a ZTYQJ series trailer type transformer oil filter oil machine. Widely used in power plant, power station, electric power company, metallurgy, petrochemical, machinery, transportation, railways and other industries, especially suitable for the large-scale transformer substation of 110 kv transformer. Deal with unqualified transformer oil, insulating oil, switch oil, quickly removing the moisture in transformer oil, gas and impurities, improve the performance of transformer oil, besides ZY - ZYX advances and ZYD inherent features and characteristics of vacuum filter oil machine, ZTYQJ's biggest advantage is can be a long field work.
Second, the characteristics of advantages:
(1), trailer type, fully closed structure, mobile convenience, but also for the field work of long distance.
Diction, especially for ?
Four, technical parameters, equipment dimensions and weight with the change of the technical parameters and change
|
The index name
|
unit
|
ZTYQJ-30
|
ZTYQJ-50
|
ZTYQJ-65
|
ZTYQJ-100
|
ZTYQJ-150
|
|
traffic
|
L/H
|
1800
|
3000
|
4000
|
6000
|
9000
|
|
Work vacuum
|
MPa
|
-0.08～-0.099
|
|
Pressure of work
|
MPa
|
≤0.4
|
|
Working temperature
|
℃
|
20 ～80
|
|
Working power supply
|
|
380V 50HZ,3Ph(Or according to customer's needs)
|
|
Working noise
|
dB(A)
|
≤65～85
|
|
Electric heating power
|
Kw
|
30
|
30
|
78
|
95
|
110
|
|
The total electrical power
|
Kw
|
35.5
|
37.5
|
87
|
104
|
121
|
|
Mouth diameter into (out of)
|
mm
|
Φ25
|
Φ25
|
Φ42
|
Φ50
|
Φ50
|
|
Equipment weight
|
kg
|
550
|
720
|
830
|
950
|
1120
|
|
The trailer weight
|
kg
|
300
|
300
|
450
|
450
|
500
|
|
The machine size
|
long
|
mm
|
1400
|
1400
|
1650
|
1700
|
1820
|
|
wide
|
mm
|
1100
|
1100
|
1200
|
1200
|
1320
|
|
high
|
mm
|
1300
|
1300
|
1500
|
1500
|
1620
|
|
Size of the trailer
|
long
|
mm
|
2750
|
2750
|
3000
|
3080
|
3400
|
|
wide
|
mm
|
1400
|
1400
|
1620
|
1620
|
1710
|
|
high
|
mm
|
1100
|
1100
|
1100
|
1100
|
1100
|
|
After the filter indicator:
|
The breakdown voltage
|
KV
|
≥70
|
|
The water content
|
ppm
|
≤0.1
|
|
Air content
|
%
|
≤0.1
|
|
impurities
|
μ
|
≤1
|
| |
|
|
|
|
|
|
|
|
Note: (product pictures for reference only, all in kind prevail, all power of interpretation and chongqing huang machinery Co., LTD. All).
